Technical sheet of OnePlus 5T
Description
The OnePlus brand has evolved its number 5 terminal with this new version T; in this case it has not opted for a simple battery upgrade, as it did with the evolution of the Oneplus 3 to the Oneplus 3T, since it has kept the 3300 mAh, but it has been really revolutionary in reducing the lateral and upper edges, following the trend of the market in borderless terminals, and moving to a 18: 9 format 6.01" screen.
On the hardware side, it continues using the current top-of-the-range processor, the Snapdragon 835, to which has been added by 6 or 8 GB of LPDDR4X RAM and a 64 or 128 GB type UFS 2.1 storage, which makes it one of the most powerful terminals in the market.
One detail that shows the power of this terminal is that it has been able to get more than 217,000 points in the Antutu test (version 7) being one of the top of the range in 2017. You can see the current Top Antutu list here . To all the above we must add one of the best cameras on the market accompanied by a Sony imx398 sensor that will delight anyone.
Brand
| Brand | OnePlus |
|---|---|
| Aliases | A5010 |
| Best Sellers |
OnePlus 5T prices
Release Date
| Release date | November 2017, 8 years ago |
|---|
Related
Design & Materials of OnePlus 5T
Image gallery
| Image gallery |
|---|
Structure
| Size | 75.0 mm•156.1 mm•7.3 mm Print 3D ModelSee more details |
|---|---|
| Weight | 162 g |
| Usable surface | 79 % |
| Materials | Aluminium alloy |
| Colors | White Red Gray |
Screen
| Diagonal |
6.01"
See more details |
|---|---|
| Type |
AMOLED
Samsung |
| Aspect Ratio | 18:9 |
| Resolution | 1080 x 2160 px • FHD+ |
| Density | 402 ppi • Very high density |
| Others |
|
151 reviews
151 reviews
151 reviews
151 reviews
Performance & Hardware of OnePlus 5T
Processor
| Model | Qualcomm Snapdragon 835 |
|---|---|
| CPU | 4x Kryo 280 2.45 GHz + 4x Kryo 280 1.9 GHz |
| Type | Octa-Core |
| Nanometer | 10 nm |
| Frequency | 2.45 GHz |
| 64 Bits | Yes |
Graphics
| GPU | Qualcomm Adreno 540 |
|---|
RAM
| RAM | 6 GB |
|---|---|
| Type | LPDDR4X RAM |
Antutu
| Score |
315.411
• Antutu v9
Overall performance better than 29% of devices
See more details |
|---|
Storage
| Capacity | 64 GB |
|---|---|
| Type | UFS Storage 2.1 |
| SD Slot | No |
Security
| Fingerprint | Yes, in the back |
|---|
Sensors
| Fingerprint | Yes |
|---|---|
| Proximity | Yes |
| Light sensor | Yes |
| Accelerometer | Yes |
| Compass | Yes |
| Gyroscope | Yes |
| Gravity | Yes |
| Hall | Yes |
| Notifications LED | Color LED Notifications |
|---|---|
| Cooling system | No |
| Gaming buttons | No |
| Extra |
|
151 reviews
151 reviews
151 reviews
Camera of OnePlus 5T
Double rear camera
Standard
| 1 |
|---|---|
| Resolution | 16 Mpx |
| Aperture | ƒ/ 1.7 |
| ISO | 100 - 3200 |
| Sensor | Sony IMX398 Exmor RS |
| Type | CMOS BSI |
| Sensor size | 1/2.8" |
| Pixel size | 1.12 µm |
- 2
- Resolution
- 20 Mpx
- Aperture
- ƒ/ 1.7
- Sensor
- Sony IMX376 Exmor RS
- Type
- CMOS BSI
- Sensor size
- 1/2.78"
- Pixel size
- 1.00 µm
- Pixel Binning
- 1-4 (2x2)
| Flash | Dual LED |
|---|---|
| Optical Stabilisation | No |
| Slow Motion Video | Yes, 120 fps |
| Features |
|
Selfie
| Resolution | 16 Mpx |
|---|---|
| Aperture | ƒ/ 2.0 |
| Sensor | Sony IMX371 Exmor |
| Type | CMOS BSI |
| Sensor size | 1/3" |
| Pixel size | 1.00 µm |
- Extra
- PDAF Focus
- Pixel size1.2 μm
- Focal length 27.22mm
- Second rear camera 20MP telephoto
- Second rear camera Sony IMX376K Exmor RS
- Second rear camera f/1.7 aperture size
- Second rear camera Pixel size 1.0 μm
- Front
- Sensor Sony IMX371 Exmor RS
- f/2.0 aperture
- Pixel size 1.0 μm
- 1080p 30fps video
151 reviews
151 reviews
151 reviews
151 reviews
photolab_detail_intro
Network compatibility
Connectivity of OnePlus 5T
Bands
| 4G LTE | B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B18 (800), B19 (800), B20 (800), B25 (1900+), B26 (850), B28b (700), B28a (700), B29 (700), B30 (2300), B34 (TDD 2100), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B66 (1700/2100) |
|---|---|
| 3G | B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B8 (900), B34 (TD 2000), B39 (TD 1900+) |
| 2G | CDMA BC0 (800), B2 (1900), B3 (1800), B5 (850), B8 (900) |
SIM card
| Type | Dual SIM
Dual Standby (Nano SIM + Nano SIM)
SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM... |
|---|
Wi-Fi
| Standards | 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac |
|---|---|
| Others |
|
Bluetooth
| Version | Bluetooth 5.0 |
|---|---|
| Profiles |
|
Navigation
| Supports | GPS, A-GPS, GLONASS, Beidou, Galileo |
|---|
USB
| Charging | Yes |
|---|---|
| Mass Storage | Yes |
| USB On-The-Go (OTG) | Yes |
| USB Type C | Yes |
SAR
| European measurement |
1.680 W/Kg on head,
1.710 W/Kg on body The European Union sets a limit of 2 W/kg averaged over 10 grams of tissue. |
|---|---|
| American measurement |
1.410 W/Kg on head,
0.510 W/Kg on body The FCC limit is 1.6 W/kg measured in a volume of 1 gram of tissue |
- NFC
- Yes
- Audio Jack
- Yes
- Radio FM
- No
- Computer sync
- Yes
- OTA sync
- Yes
- Tethering.
- Yes
- DLNA
- Yes
- VoLTE
- Yes
151 reviews
151 reviews
151 reviews
Battery of OnePlus 5T
| Capacity | 3300 mAh See more details |
|---|---|
| Type | Li-Polymer |
| Fast charge | Yes |
| Others |
|
| Extra |
|
- 15%Two days or more
- 48%More than one day
- 28%One day
- 8%Less than a day
- 1%Less than half day
151 reviews
Software of OnePlus 5T
Software
| Operating System |
Android 10
Q
Android 10 |
|---|---|
| Google Services | With Google Mobile Services |
- 42%It comes with a clean operating system
- 54%It has preinstalled apps but they don't bother me
- 4%It has preinstalled apps that I can't uninstall
151 reviews
- 62%Every two months or less
- 28%Every six months
- 4%Once a year
- 5%Never
151 reviews
