Technical sheet of Asus ROG Phone 7

Description

Introducing the Asus ROG Phone 7: The Ultimate High-End Smartphone From Asus

Asus is a well-established global leader in the gaming and technology industries, and the release of the Asus ROG Phone 7 marks the latest step in the brand's commitment to delivering premium performance and cutting-edge technology. With powerful hardware and a range of features designed to make your gaming experience as immersive as possible, the Asus ROG Phone 7 is sure to please even the most discerning gamer.

The Asus ROG Phone 7 has been crafted with the highest quality materials, including Corning Gorilla Glass victus, which is the most durable glass available. The phone also features an impressive 81.8% usable surface area and a stunning AMOLED display with 6.78 inch screen, 1080 x 2448 (FHD+) resolution, 165 Hz refresh rate, and high brightness of HBM – 1000 cd/m², as well as HDR10+ compatibility.

For audio, the Asus ROG Phone 7 sports two symmetrical stereo speakers with Dirac HD Sound and an impressive 5-magnet design that delivers crystal clear sound quality. It also comes equipped with a noise cancellation microphone, Hi-Res Audio up to 384 kHz / 32-bit for 3.5mm output, Qualcomm WCD938, and DTS / DTS X.

Under the hood, the Asus ROG Phone 7 is powered by the Qualcomm Snapdragon 8 Gen2 (4nm) processor and 16/8/12GB RAM LPDDR5X. It comes with 512/256GB UFS Storage 4.0 and AnTuTu (v9) rating of 1333600. Security features on the phone include Fingerprint Display and Gaming Buttons. In addition, it comes with a Matrix liquid cooling architecture 7.0, which consists of a vacuum chamber and 16000mm² graphene for superior levels of cooling.

The Asus ROG Phone 7 also comes with a triple camera setup, including a Sony IMX766 with 50.0Mpx, f/1.9 CMOS, an Omnivision OV13B10 wide-angle lens with 13.0Mpx and f/2.2, and a Samsung S5K5E9 macro lens with 5.0Mpx and f/2.4. On the front, you get a Omnivision OV32C selfie camera with 32.0Mpx, f/2.5, and 0.700 pixel size. Both front and back cameras are capable of 4K and 8K video recording.

Finally, the Asus ROG Phone 7 offers a huge 6000mAh battery that can be quickly charged up to 65.0W, and it also supports reverse charging. For connectivity, the phone is equipped with Bluetooth 5.3, dual SIM, NFC, audio jack, WiFi 6 (802.11ax), GPS (L1+L5). However, it does not support 5G bands N18, N26 and N40 in Japan.

All in all, the Asus ROG Phone 7 is a top-tier smartphone with powerful hardware, excellent design and materials, and cutting-edge audio and camera technologies. It is the ideal choice for gamers who demand the ultimate in performance and power. If you're looking for a flagship smartphone that can deliver an unparalleled gaming experience, then look no further than the Asus ROG Phone 7.

Read More

Brand

Brand Asus
Aliases AI2205_A
Best Sellers
Smartphones by Asus

Asus ROG Phone 7 prices

Versions and prices
Asus ROG Phone 7 Global · 16GB · 512GB · VB $ 801
Asus ROG Phone 7 Global · 12GB · 256GB · VB $ 655
Asus ROG Phone 7 China · 8GB · 256GB · VC $ 605
Asus ROG Phone 7 China · 12GB · 256GB · VC $ 657
Asus ROG Phone 7 China · 16GB · 512GB · VC $ 726
Asus ROG Phone 7 N. America · 12GB · 256GB · VA $ 754
Asus ROG Phone 7 N. America · 16GB · 512GB · VA $ 898
Read More

Release Date

Release dateApril 2023, 7 months ago

Related

Predecessor
Similar name

Design & Materials of Asus ROG Phone 7

Image gallery

Image gallery
  • Kimovil Video Samples Videos Asus Rog Phone 7 Promo Video
  • where to buy Asus ROG Phone 7
  • best price for Asus ROG Phone 7
  • deals for Asus ROG Phone 7
  • stores that sells Asus ROG Phone 7
  • buy cheap Asus ROG Phone 7
  • where to buy Asus ROG Phone 7

Structure

Size
77.0 mm173.0 mm10.3 mm
Print 3D Model
Weight 239 g
Usable surface 82 %
Materials Glass , Corning Gorilla Glass
Resistance certificates (dust, water) IP54
Colors
Black
White

Screen

Diagonal
6.78"
Type AMOLED
Samsung
Aspect Ratio 20:9
Resolution 1080 x 2448 px FHD+
Density 380 ppi High Density
Others
  • Without Notch
  • Eye Care Display
  • Refresh rate 165 Hz
  • Touch sampling rate 720 Hz
  • Peak brightness - 1500 cd/m²
  • Max brightness HBM - 1000 cd/m²
  • Always-On Display
  • TÜV Rheinland Eye Comfort Certification
  • HDR10+
  • DCI-P3
  • DC dimming
  • sRGB standard
  • NTSC
  • Color LED Notifications
  • Scratch resistant
  • Corning Gorilla Glass Victus
  • Capacitive
  • Multi-touch
  • Physical buttons
  • 1 ms response time
  • Oleophobic coating
Best big screen mobilesBest mobile phones with AMOLED screen
Audio
Audio
  • DTS / DTS X
  • Hi-Res Audio
  • Noise cancellation microphone
  • Stereo Speakers
  • 3 microphones
Others
Audio
Symmetrical dual front-facing speakers with Dirac HD Sound
5-magnet stereo speaker with Cirrus Logic amplifier.
Hi-Res Audio up to 384 kHz / 32-bit for 3.5mm output
Qualcomm WCD938

Performance & Hardware of Asus ROG Phone 7

Processor

Model Qualcomm Snapdragon 8 Gen2
CPU 1x3.2GHz CortexX3 + 2x2.8 GHz CortexA715 + 2x2.8 GHz CortexA710 + 3x2.02 GHz CortexA510
Type Octa-Core
Nanometer 4 nm
Frequency 3.2 GHz
64 Bits Yes
More smartphones with Qualcomm Snapdragon 8 Gen2 processor

Graphics

GPU Qualcomm Adreno 740

RAM

RAM 12 GB
Type RAM LPDDR5X
More smartphones with 12GB RAM memory

Antutu

Score
1.603.292 Antutu v10
Overall performance better than 99% of devices

Storage

Capacity 256 GB
Type UFS Storage 4.0
SD Slot No
More smartphones with 256GB of internal storage

Security

Fingerprint Yes, in screen

Sensors

Fingerprint Yes
Proximity Yes
Light sensor Yes
Accelerometer Yes
Compass Yes
Gyroscope Yes
Hall Yes
Others
Notifications LED Color LED Notifications
Cooling system Yes
Gaming buttons Yes
Extra
  • Matrix liquid cooling architecture 7.0 (vacuum chamber chamber + 16000mm² graphene)

Camera of Asus ROG Phone 7

Triple rear camera

Standard
1
Resolution 50 Mpx
Sensor Sony IMX766
Type CMOS
Aperture ƒ/ 1.9
ISO --
Pixel size 1.00 µm
Pixel Binning 1-4 (2x2)
Sensor size 1/1.56"
2
Resolution
13 Mpx
Sensor
Omnivision OV13B10
Type
PureCel
Aperture
ƒ/ 2.2
Pixel size
1.12 µm
Sensor size
1/3.06"
3
Resolution
5 Mpx
Sensor
Samsung S5K5E9
Type
ISOCELL
Aperture
ƒ/ 2.4
Pixel size
1.12 µm
Sensor size
1/5"
Flash LED
Optical Stabilisation No
Slow Motion Video Yes, 480 fps
Features
  • 4K Video
  • 8K Video
  • Digital zoom
  • Triple camera
  • Digital image stabilization
  • Autofocus
  • Touch focus
  • Manual focus
  • Phase detection autofocus (PDAF)
  • Continuous shooting
  • Geotagging
  • Panorama
  • HDR
  • Face detection
  • White balance settings
  • ISO settings
  • Exposure compensation
  • Scene mode
  • Self-timer
  • RAW
  • Night Mode
More smartphones with IMX766 lens modelMore smartphones with LED

Selfie

Resolution 32 Mpx
Sensor Omnivision OV32C
Type PureCel
Aperture ƒ/ 2.5
Pixel size 0.70 µm
Pixel Binning 1-4 (2x2)
Sensor size 1/3.2"
Kimovil Frequency Checker

Network compatibility

Connectivity of Asus ROG Phone 7

Bands

5G n1 (2100), n2 (1900 PCS), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n18 (850), n20 (800), n25 (1900), n26 (850), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n48 (3500), n66 (1700), n77 (3700), n78 (3500), n79 (4700)
4G LTE B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B18 (800), B19 (800), B20 (800), B25 (1900+), B26 (850), B28b (700), B28a (700), B32 (1500), B34 (TDD 2100), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B43 (TDD 3700), B48 (TDD 3600), B66 (1700/2100)
3G B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B6 (800), B8 (900), B19 (800)
2G B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

TypeDual SIM Dual Standby (Nano SIM + Nano SIM)

SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac, 802.11ad , WiFi 6 (802.11ax) , Wi-Fi 7 (802.11be)
Others
  • Dual band
  • Wi-Fi Hotspot
  • Wi-Fi Direct
  • Wi-Fi Display
  • Wi-Fi MiMO

Bluetooth

Version Bluetooth 5.3
Profiles
  • A2DP (Advanced Audio Distribution Profile)
  • AVRCP (Audio/Visual Remote Control Profile)
  • EDR (Enhanced Data Rate)
  • GAP (Generic Access Profile)
  • HFP (Hands-Free Profile)
  • HID (Human Interface Profile)
  • HSP (Headset Profile)
  • MAP (Message Access Profile)
  • PAN (Personal Area Networking Profile)
  • OPP (Object Push Profile)
  • PBAP/PAB (Phone Book Access Profile)
  • HDP (Health Device Profile)
  • APT-x
  • LDAC
  • AAC

Navigation

Supports GPS, A-GPS, GLONASS, Beidou, QZSS, Galileo, GPS (L1+L5), BeiDou (B1), Galileo (E1+E5a), BeiDou (B2), NavIC System, QZSS (L1 + L5)

USB

Charging Yes
Mass Storage Yes
USB On-The-Go (OTG) Yes
USB Type C Yes
USB Host 3.1 Yes

SAR

European measurement 1.485 W/Kg on head, 1.579 W/Kg on body

The European Union sets a limit of 2 W/kg averaged over 10 grams of tissue.

What is the SAR of Asus ROG Phone 7?
Others
NFC
Yes
Audio Jack
Yes
Radio FM
No
Computer sync
Yes
OTA sync
Yes
Tethering.
Yes
VoLTE
Yes
Bands for JP
  • 5G bands N18, N26 and N40 not available in JP

Battery of Asus ROG Phone 7

Capacity
6000 mAh
Type Li-Polymer
Fast charge Yes , 65.0W
Others
  • Bypass Charging
  • Reverse charging
  • Non-removable
Extra
  • USB power adapter (65-Watt) / 30-watt in India
  • 10W reverse wired

Software of Asus ROG Phone 7

Software

Operating System Android 13 Tiramisu
Android 13
Google Services (official) Yes
More smartphones with Android 13 operating system

User reviews about the Asus ROG Phone 7

Overall satisfaction
Not enough reviews
1 review
  • Screen7.0
  • Performance9.7
  • Camera5.3
  • Connectivity10
  • Battery9.0
Want to comment on the Asus ROG Phone 7?

It'll only take a minute, you'll help people decide.

Latest reviews added

Compare

Add to compare

Compared with...

Questions · FAQ

Frequently asked questions about the Asus ROG Phone 7.

What are the features of the Asus ROG Phone 7?

These are the main features and specifications of the Asus ROG Phone 7:

  • Screen: 6.78" AMOLED
  • Resolution: 1080 x 2448 px · FHD+
  • RAM: 8GB - 16GB
  • Storage: 256GB - 512GB
  • Processor: Qualcomm Snapdragon 8 Gen2

How long does the battery of the Asus ROG Phone 7 last?

The Asus ROG Phone 7 battery has a capacity of 6000 mAh.

In which colours is the Asus ROG Phone 7 available?

The Asus ROG Phone 7 is available in 2 colours: Black and White.

When was the Asus ROG Phone 7 release date?

The Asus ROG Phone 7 was unveiled on Thursday, April 13, 2023.

Does the Asus ROG Phone 7 have 5G?

Asus ROG Phone 7 has 5G on 21 bands: n1 (2100), n2 (1900 PCS), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n18 (850), n20 (800), n25 (1900), n26 (850), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n48 (3500), n66 (1700), n77 (3700), n78 (3500) and n79 (4700).

Which camera does the Asus ROG Phone 7 have?

The Asus ROG Phone 7 has a triple rear camera and its main sensor is Sony IMX766 with a resolution of 50Mpx.
