Technical sheet of Samsung Galaxy M54

Description

The Samsung Galaxy M54 is the South Korean tech giant's latest foray into the mid-range market, with a release date of March 2023. This latest device from Samsung offers exceptional performance, enhanced display, and powerful camera tech in an attractive, lightweight body. The device is sure to attract a lot of attention from the budget-minded consumer looking for a quality device.

Design & Materials

The Samsung Galaxy M54 has a minimalist design, with a sleek metal frame encasing the device. The back of the device is made of plastic, giving it an affordable yet durable feel. It is fitted with a 6.70-inch Super AMOLED display with a resolution of 1080x2400 (FHD+) and a refresh rate of 120 Hz. The screen has a usable surface area of 84.6%, making it easy to navigate and use. To protect the screen from scratches and drops, the device is covered with Corning Gorilla Glass 5.

Hardware

When it comes to performance, the device does not disappoint. It is powered by the Exynos 1380 (5nm) processor, which is perfectly suited for gaming and multitasking. It is paired with 8GB of LPDDR4X RAM, giving the user a seamless experience when switching between apps. Storage-wise, it offers two options: 128GB and 256GB, making it easy to store all your data. It also has external storage via MicroSD in the Slot Card Tray. AnTuTu 9 scores this device around 507000 points. Security-wise, it has a fingerprint scanner on the side for unlocking.

Camera

The Samsung Galaxy M54 sports a triple camera setup at the back—a standard Samsung HM6 with a resolution of 108.0Mpx and f/1.8 aperture, a wide-angle lens with 8.0Mpx and f/2.2 aperture and 1.120 pixel size, and a macro lens with 2.0Mpx and f/2.4 aperture. On the front, there is a 32.0Mpx selfie camera with f/2.2 aperture and CMOS sensor. Both cameras are equipped with Optical Stabilization (OIS) for improved image quality and support 4K video.

Connectivity

For connectivity, the device is equipped with Bluetooth 5.3, dual SIM, NFC, and WiFi 6 (802.11ax). It is also compatible with 5G networks, making it a great choice if you plan on taking advantage of 5G speeds and coverage.

Battery

The Samsung Galaxy M54 packs a 6000mAh battery that supports fast charging up to 25W, allowing you to quickly charge your device when needed.

Conclusion

The Samsung Galaxy M54 is a great choice for consumers looking for a reliable mid-range device. With a powerful processor, enhanced display, and powerful camera tech, the device is sure to be a hit among budget-minded consumers. Add to that the sleek design and the long-lasting battery, and you have a device that won't let you down.

Read More

Brand

Brand Samsung
Aliases SM-M546B, SM-M546B/DS, SM-M546BZSHMEC, Samsung Galaxy M54 5G
Best Sellers
Smartphones by Samsung

Samsung Galaxy M54 prices

Versions and prices
Samsung Galaxy M54 Global · 8GB · 128GB · SM-M546B
Samsung Galaxy M54 Global · 8GB · 256GB · SM-M546B $ 463
Samsung Galaxy M54 N. America · 8GB · 128GB · SM-M546M $ 374

Release Date

Release dateMarch 2023, 2 months ago

Related

Predecessor

Design & Materials of Samsung Galaxy M54

Image gallery

Image gallery
  • where to buy Samsung Galaxy M54
  • best price for Samsung Galaxy M54
  • deals for Samsung Galaxy M54
  • stores that sells Samsung Galaxy M54
  • buy cheap Samsung Galaxy M54
  • where to buy Samsung Galaxy M54
  • best price for Samsung Galaxy M54
  • deals for Samsung Galaxy M54
  • stores that sells Samsung Galaxy M54
  • buy cheap Samsung Galaxy M54
  • where to buy Samsung Galaxy M54
  • best price for Samsung Galaxy M54
  • deals for Samsung Galaxy M54

Structure

Size
77.3 mm 164.9 mm 8.4 mm
Print 3D Model
Weight 199 g
Usable surface 85 %
Materials Plastic
Colors
Blue
Silver

Screen

Diagonal
6.7"
Type Super AMOLED
Aspect Ratio 20:9
Resolution 1080 x 2400 px FHD+
Density 393 ppi High Density
Others
Best big screen mobilesBest mobiles with SuperAMOLED screen

Performance & Hardware of Samsung Galaxy M54

Processor

Model Exynos 1380
CPU 4x2.4GHz ARM CortexA78 + 4x2.0 GHz ARM CortexA55
Type Octa-Core
Nanometer 5 nm
Frequency 2.4 GHz
64 Bits Yes
More smartphones with Exynos 1330 processor

Graphics

GPU ARM Mali-G68 MP5

RAM

RAM 8 GB
Type LPDDR4X RAM
More smartphones with 8GB RAM memory

Antutu

Score
507.000 Antutu v9
Overall performance better than 82% of devices

Storage

Capacity 128 GB
Type --
SD Slot Yes , Slot for SD or second SIM card
More smartphones with 128GB of internal storage

Security

Fingerprint Yes, on the side

Sensors

Fingerprint Yes
Proximity Yes
Light sensor Yes
Accelerometer Yes
Compass Yes
Gyroscope Yes
Geomagnetic Yes
Others
Notifications LED --
Cooling system No
Gaming buttons No

Camera of Samsung Galaxy M54

Triple rear camera

Standard
1
Resolution 108 Mpx
Sensor Samsung HM6
Type ISOCELL
Aperture ƒ/ 1.8
ISO --
Pixel size 0.64 µm
Pixel Binning 1-9 (3x3)
Sensor size 1/1.67"
2
Resolution
8 Mpx
Sensor
--
Type
CMOS
Aperture
ƒ/ 2.2
Pixel size
1.12 µm
3
Resolution
2 Mpx
Sensor
--
Type
CMOS
Aperture
ƒ/ 2.4
Pixel size
--
Flash LED
Optical Stabilisation Yes
Slow Motion Video Yes, 240 fps
Features
  • 4K Video
  • Digital zoom
  • Triple camera
  • Digital image stabilization
  • Optical Stabilization (OIS)
  • Autofocus
  • Touch focus
  • Phase detection autofocus (PDAF)
  • Continuous shooting
  • Geotagging
  • Panorama
  • HDR
  • Face detection
  • White balance settings
  • ISO settings
  • Exposure compensation
  • Scene mode
  • Self-timer
More smartphones with HM6 lens modelMore smartphones with LED

Selfie

Resolution 32 Mpx
Sensor --
Type CMOS
Aperture ƒ/ 2.2
Pixel size --
Kimovil Frequency Checker

Network compatibility

Connectivity of Samsung Galaxy M54

Bands

5G n1 (2100), n3 (1800), n5 (850), n7 (2600), n8 (900), n28b (700), n28a (700), n40 (2300), n41 (2500), n77 (3700), n78 (3500)
4G LTE B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B20 (800), B26 (850), B28b (700), B28a (700), B38 (TDD 2600), B40 (TDD 2300), B41 (TDD 2500), B66 (1700/2100)
3G B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B8 (900)
2G B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

TypeDual SIM Dual Standby (Nano SIM + Nano SIM)

SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac, WiFi 6 (802.11ax)
Others
  • Dual band
  • Wi-Fi Hotspot
  • Wi-Fi Direct
  • Wi-Fi Display

Bluetooth

Version Bluetooth 5.3
Profiles
  • A2DP (Advanced Audio Distribution Profile)
  • AVRCP (Audio/Visual Remote Control Profile)
  • DIP (Device ID Profile)
  • HFP (Hands-Free Profile)
  • HID (Human Interface Profile)
  • HSP (Headset Profile)
  • MAP (Message Access Profile)
  • PAN (Personal Area Networking Profile)
  • OPP (Object Push Profile)
  • PBAP/PAB (Phone Book Access Profile)
  • HOGP
  • LDAC
  • SBC

Navigation

Supports GPS, A-GPS, GLONASS, Beidou, QZSS, Galileo, NavIC System

USB

Charging Yes
Mass Storage Yes
USB On-The-Go (OTG) Yes
USB Type C Yes

SAR

European measurement 0.490 W/Kg on head, 1.200 W/Kg on body

The European Union sets a limit of 2 W/kg averaged over 10 grams of tissue.

What is the SAR of Samsung Galaxy M54?
Others
NFC
Yes
Audio Jack
No
Radio FM
No
Computer sync
Yes
OTA sync
Yes
Tethering.
Yes
VoLTE
Yes

Battery of Samsung Galaxy M54

Capacity
6000 mAh
Type Li-Ion
Fast charge Yes , 25.0W
Others
  • Non-removable

Software of Samsung Galaxy M54

Software

Operating System Android 13 Tiramisu
Android 13
Google Services (official) Yes
More smartphones with Android 13 operating system

User reviews about the Samsung Galaxy M54

Overall satisfaction
Not enough reviews
No user reviews
    Want to comment on the Samsung Galaxy M54?

    It'll only take a minute, you'll help people decide.

    Compare

    Add to compare

    Compared with...

    Questions · FAQ

    Frequently asked questions about the Samsung Galaxy M54.

    What are the features of the Samsung Galaxy M54?

    These are the main features and specifications of the Samsung Galaxy M54:

    What is the price of Samsung Galaxy M54?

    The price of the Samsung Galaxy M54 in United States varies between 374$ and 463$ depending on the specific version and its features. Below you can see the current prices for the different Samsung Galaxy M54 versions:

    How long does the battery of the Samsung Galaxy M54 last?

    The Samsung Galaxy M54 battery has a capacity of 6000 mAh.

    In which colours is the Samsung Galaxy M54 available?

    The Samsung Galaxy M54 is available in 2 colours: Blue and Silver.

    When was the Samsung Galaxy M54 release date?

    The Samsung Galaxy M54 was unveiled on Thursday, March 23, 2023.

    Does the Samsung Galaxy M54 have 5G?

    Samsung Galaxy M54 has 5G on 11 bands: n1 (2100), n3 (1800), n5 (850), n7 (2600), n8 (900), n28b (700), n28a (700), n40 (2300), n41 (2500), n77 (3700) and n78 (3500).

    Which camera does the Samsung Galaxy M54 have?

    The Samsung Galaxy M54 has a triple rear camera and its main sensor is Samsung HM6 with a resolution of 108Mpx.
